技术参数/Technical Characteristic

电缆结构/Cable Construction

内导体/Inner conductor

0.54mm

7strands silver plated copper

绝缘/Insulation

1.52mm

Extruded PTFE

外导体/Outer conductor

1.98mm

Silver plated copper braiding

护套/Jacket

2.49mm

PTFE tape wrapped, White

电性能参数/Electrical Cable Characteristic

Capacitance

96.5pF/m

阻抗/Impedance

50ohm

速率/Velocity of Propagation

69.5%

工作频率/Operation frequency

3.0GHz

最大工作电压/Voltage Withstanding

1200VRMS

机械性能参数/Mechanical Cable Characteristic

最小弯曲半径(静态)/Inside Bend Radius (Minimum)

12.7mm

重量/Weight

16.2g/m

工作温度/Operating Temperature

-65 up to +250℃

RoHS符合/RoHS Compliant

是/Yes

衰减/Cable Attenuation

频率/Frequency(GHz）

衰减/Attenuation(dB/m)

0.100

0.249

0.400

0.525

1.000

0.860

2.400

1.351
